MEC-WIFI-2532B-30
Industrial M.2 PCIe Wi-Fi Expansion Card_2532B-30
Features
- Form factor: NGFF M.2 2230 type
- IEEE 802.11a/b/g/n/ac draft 2.0 compatible WLAN
- WLAN supports 2.4GHz and 5GHz channel
- 2T2R MIMO technology for extended reception robustness and exceptional throughput
- Bluetooth: BT 2.1/3.0/4.0/4.1/4.2
MEC-WIFI-2532B-30 is a highly integrated single-chip that support 2-stream 802.11ac solutions with Multi‐user MIMO (Multiple‐Input , Multiple‐Output) with Wireless LAN(WLAN) PCI Express network interface controller with integrated Bluetooth Smart Ready USB interface controller. It combines a WLAN MAC, a 2T2R capable WLAN baseband, and RF in s single chip.
MEC-WIFI-2532B-30 provides a complete solution for a high- performance integrated wireless and Bluetooth device.
MEC-WIFI-2532B-30 provides a complete solution for a high- performance integrated wireless and Bluetooth device.
Solution
Wi-Fi
Form Factor
M.2 2230 (A+E key)
Interface
WLAN: PCIe 1.1 / Bluetooth: USB2.0
Frequency Range
802.11 a/b/g/n/ac + Bluetooth 4.2
Chipset
Realtek RTL8822BE
T/R
2T2R
Dimensions (WxL/ mm)
30.0 x 22.0
Operation Temp.
0°C ~ 70°C
Driver Support
Win 7, Win 8, Win 10, Linux, Android
Warranty
1 year
| Model No. | Description |
|---|---|
| MEC-WIFI-2532B-30 | WLAN 802.11 a/b/g/n/ac 2T2R BT 4.2 NGFF Card M.2 Type 2230 key-A-E |
