R335 Family
Industrial 2.5" SATA SSD
Features
- Compliant with SATA III 6.0Gb/s
- RO-MLC technology
- Capacity: 16GB ~ 256GB
- With DRAM Buffer
- Operating as boot disk
- Low power consumption
- Shock resistance and anti-vibration
- Static and dynamic wear leveling
- Bad block management
- S.M.A.R.T. & TRIM command
Cervoz Industrial 2.5" SATA SSD R335 family is a high capacity Solid State Disk product that is in compliance with the 2.5" form factor and SATA III standards. The device design is based on the 7pin for data segment and 15pin for power segment standards.
R335 family uses preselected multi-level cell (MLC) NAND flash memory from the industry leading manufacturer Micron and utilizes our "Reliability Optimized-MLC (RO-MLC) Technology". We adopt specialized firmware to control MLC NAND flash which only uses the strong pages of MLC NAND as storage; the technology is manipulated at the block level, and with each block's capacity halved by treating it as SLC. This product includes various capacities to choose from.
R335 family offers high performance with reliability and endurance, as well as a remarkable price-performance ratio, ideal for applications in harsh environments. Industrial PC/Embedded PC, Factory Automation, Transportation, Information & Entertainment and Server & Cloud Computing all benefit from this superior reliability and cost-effectiveness.
R335 family uses preselected multi-level cell (MLC) NAND flash memory from the industry leading manufacturer Micron and utilizes our "Reliability Optimized-MLC (RO-MLC) Technology". We adopt specialized firmware to control MLC NAND flash which only uses the strong pages of MLC NAND as storage; the technology is manipulated at the block level, and with each block's capacity halved by treating it as SLC. This product includes various capacities to choose from.
R335 family offers high performance with reliability and endurance, as well as a remarkable price-performance ratio, ideal for applications in harsh environments. Industrial PC/Embedded PC, Factory Automation, Transportation, Information & Entertainment and Server & Cloud Computing all benefit from this superior reliability and cost-effectiveness.
Series
Reliance Series (RO-MLC)
Form Factor
2.5 inch
Interface
SATA III 6.0Gb/s
Connector
SATA (7 + 15 pin)
NAND Flash Type
3D MLC (Controlled by Reliability Optimized-MLC Technology)
Capacity
16GB ~ 256GB
Dimension (LxWxH/mm)
100.00 x 69.85 x 7.00
Sequential Read
up to 550MB/s
Sequential Write
up to 465MB/s
ECC Scheme
up to 66bits / 1K Byte
MTBF
>3,000,000 hours
Terabyte Written (TBW)
16GB : 130.2, 32GB : 260.4, 64GB : 520.8, 128GB : 1041.7, 256GB : 2083.3
Operating Temperature: Standard Temp.
0°C ~ 70°C
Operating Temperature: Wide Temp.
–40°C ~ 85°C
Supply Voltage
5V DC +/-5%
Power Consumption
Active mode: < 2200mW, Idle mode: < 445mW
With DRAM Buffer
✓
Conformal Coating
Optional
Anti-Vibration Fill
Optional
FlashMonitor
✓
| Standard Temp. (0°C ~ 70°C) | Wide Temp. (-40°C ~ 85°C) | Capacity |
|---|---|---|
| CIS-2SR335MKD016GS | CIS-2SR335MKD016GW | 16GB |
| CIS-2SR335MKD032GS | CIS-2SR335MKD032GW | 32GB |
| CIS-2SR335MKD064GS | CIS-2SR335MKD064GW | 64GB |
| CIS-2SR335MKD128GS | CIS-2SR335MKD128GW | 128GB |
| CIS-2SR335MKD256GS | CIS-2SR335MKD256GW | 256GB |
| Date | Document Type | Capacity |
|---|---|---|
| 2022.06.21 | Industrial_SSD_2.5_inch_SATA_R335_Datasheet_Rev3.1 | 1.28 MB |
